  • Peltitarvike inverted structure drain KK dimensions

Roof drain KK with horizontal outlet

Drain with collection basin suitable for drainage of inverted structures. The inverted structure drain is always used together with a suitable screen structure. The drain made of acid-resistant steel withstands demanding weather conditions and temperature fluctuations.

The drains have a primed flange that ensures a secure connection to the bitumen membrane. Drains can also be ordered without a primed flange for other waterproofing membranes.

Technical data
Model
KK
Material
Acid-resistant steel
Outlet location
Side
Outlet diameter ∅
75 or 110 mm
Outlet length
200 or 500 mm
Diameter of the collection basin ∅
220 mm
Depth of the collection basin
100 or 136 mm
Flange diameter ∅
530 mm

Other sizes can be made to order.

Accessories

Self-adjusting thermocable (16W or 32W)

The roof drain with thermocable stays unfrozen in winter conditions. Available with 2, 3, 5, 10, 15, 20 and 25 m connection cable.

Condensation insulation (13mm cellular rubber)

Cellular rubber insulation prevents warm indoor air from entering the surface of the cold drain pipe, which prevents the accumulation of possible condensation on the surface of the pipe or drain. Temperature range -40° – +85°.

Bitumen flange (580x600 mm)

The bitumen flange provides the best possible connection between the drain and the waterproofing.

LVI-numbers
Product LVI-nro
KK-75/200, horizontal 3380418
KK-75/500, horizontal 3380419
KK-110/200, horizontal 3380437
KK-110/500, horizontal 3380438

Documents and images

Certifications and approvals

Tested in accordance with SFS-EN 1253-2.

The European standardisation organisation CEN has not defined a harmonised product standard (hEN) for roof drains, on the basis of which the product could be CE marked. The product eligibility of the roof drain is determined by site-specific certification.

Maintenance and spare parts

Maintenance of the screen structure in accordance with the product maintenance instructions. Other maintenance measures in accordance with the property service manual.

Objects for the designer

BIM and CAD models of Peltitarvike's drainage products can be found in the ProdLib and MagiCAD product libraries.

ProdLib
MagiCAD
