    Screen structure for green roof and drain KK
  • Screen structure for green roof dimensions
    Height made to order

Screen structure for green roof, VKV

Screen structure with two-part adjustable extension ring for drainage of green areas and roofs. The screen structure has a thermally insulated cover.

Compatible with inverted structure drain model KK.

Technical data
Material
Acid-resistant steel
Cover frame
240x240 mm
Extension ring diameter ∅
220 mm
Height adjustment range*

70-85, 80-100, 90-110, 100-130, 115-150, 140-190, 170-230, 195-290, 265-410, 355-560 or 485-840 mm

* Height from waterproofing to finished surface

Other sizes made according to the order.

LVI-numbers
Height adjustment range LVI-nro
70-85 mm 3381220
80-100 mm 3381221
90-110 mm 3381222
100-130 mm 3381223
115-150 mm 3381224
140-190 mm 3381225
170-230 mm 3381226
195-290 mm 3381227
265-410 mm 3381228
355-560 mm 3381229
485-840 mm 3381230

Documents and images

Maintenance

Surface installation, cover inspection and cleaning. In the case of concealed installation, marking location on the site plan.

Objects for the designer

BIM and CAD models of Peltitarvike's drainage products can be found in the ProdLib and MagiCAD Cloud product libraries.

ProdLib
MagiCAD Cloud
Compatible products

Inverted structure drain and separation trim

With the help of our technical sales, you can find a solution that works for even the most demanding site!
