  • PITO roof equipment stand dimensions
Standard

PITO™ roof equipment stand

The PITO roof equipment stand is a robust and safe stand that allows various devices and equipment such as engine rooms, ventilation equipment and flagpoles to be attached to the roof.

The standard size PITO roof equipment stand is a stocked product that guarantees fast delivery. The removable top plate allows the roof equipment stand to be shortened to the desired height on site. The galvanisation of the cut point must be taken care of on site. Top plate available in different shapes on request.

Technical data

Base
Reinforced concrete slab, TT slab, hollow-core slab
Material
Steel, hot-dip galvanised and internally condensation-insulated
Pipe height
600, 1000 or 1400 mm
Pipe diameter ∅
88,9 mm
Wall thickness
4 mm
Base plate diameter ∅
350 mm
Base plate thickness
10 mm
Base plate hole pitch
212 mm
Hole diameter ∅
24 mm

Documents and images

With the help of our technical sales, you can find a solution that works for even the most demanding site!
